Low-Voltage DC Power Analyzer Kit

About the project

An educational project that leaves the learner with a practical engineering instrument for future electronics work. You will measure voltage and current, calculate power and accumulated energy, read the measurement IC, process the data, display live values, and optionally log readings when supported by the final implementation. This product is strictly for low-voltage DC use within the validated operating limits of the final hardware design. It must never be presented as a mains, 220V, or AC measurement device

Receive the complete kit, build the project yourself, program it from scratch, understand how it works, and finish with a useful working device you can keep

What you will build

A reusable low-voltage DC power analysis tool for testing and measuring future electronics projects

What you will learn

• Understand voltage, current, power, and energy
• Read a digital electrical measurement IC
• Use I2C communication
• Sample and process measurement data
• Calculate power from measured values
• Accumulate energy usage
• Present measurements clearly
• Learn basic calibration and validation
• Test an electronic measurement instrument
• Understand safe low-voltage operating limits

What is included

How the learning experience works

1. Learn
2. Wire
3. Assemble
4. Program
5. Test
6. Use

Difficulty and experience

Intermediate

Intermediate. Basic electrical concepts are useful, but the course explains the measurement principles before implementation
